OPERATION

It has 10 channels for bipolar applications (bipolar interferential or Russian waves) and 5-Channel for tetrapolar interferencial.

The emission of waves is completely digitized and microcontrolled, giving greater accuracy to the parameterization of programs and greater equipment reliability.

DIFFERENTIAL ADVANTAGE
The characteristics of the circuit makes the emission intensity remains unchanged regardless of the number of active channels.
– 34 preset programs for condition.
– 15 user defined programs.

This versatile device allows you to offer full treatments, over large body areas in one session. Among its many applications you can choose from:

Russian Bipolar Interferential waves or currents into ten regions or different muscles simultaneously, Interferential tetrapolar Current in five areas (1000 or 4000 Hz). The output channels of Interferential Tetrapolar Currents are configured by combining 2 bipolar channels, without wires or special electrodes for this application.

It also allows the regulation of the stimulus / pause time ratio and contraction in Russian waves. The control of the output current is individual for each channel using digital mono-command 360 degree control, regulated by a microcontroller, ensuring greater accuracy and consistency in the output. RESULTS The beneficial effect of interferential currents in muscle tone, is highly known for its effectiveness, being widely applied in cosmetic treatments, rehabilitation and pain.

Also, the Russian waves (or Kotz currents) are used for decades in sports medicine and aesthetics as a very effective tool for muscle hypertrophy, in order to model, gain muscle volume, or improve the characteristics of the muscle to increase athletic performance.

INCLUDES
4 Band clamp 0.50 M
4 Band clamp 0.70M
2 Band clamp 1.20 M
20 Rubber electrodes 0.90
20 Wipes electrodes

DIMENSIONS
Equipment: 7 kg
Accessories: 1 kg
Packing: 4 kg Total: 12 kg
Dimensions: 20 x 56 x 43 cm (high-long-deep)
